Case CX210D, CX230D Long Reach Crawler Excavator Pdf Repair and Service Manual
Case CX210D, CX230D Long Reach Crawler Excavator Pdf Repair and Service Manual
⭐⭐⭐⭐⭐ 50+ Reviews
Couldn't load pickup availability
Case CX210D, CX230D Long Reach Crawler Excavator PDF Repair and Service Manual
If you are looking for the correct workshop reference for a CASE CX210D, CX210D Long Reach or CX230D, this service manual brings the machine's major repair systems together in one searchable PDF. It is particularly useful for jobs that go beyond routine servicing, from hydraulic and engine work to track repairs, electrical diagnosis and boom or bucket service.
The identified publication is Part No. 47961275, English, dated February 2016, and covers the Tier 4 Final European-market configurations listed below. ([turn0search4])
Manual Specification
| Item | Details |
|---|---|
| Brand | CASE Construction Equipment |
| Models | CX210D, CX210D Long Reach, CX230D |
| Publication Number | 47961275 |
| Manual Type | Service / Repair Manual |
| Publication Date | February 2016 |
| Market | European Union |
| Emission Version | Tier 4 Final |
| Language | English |
| Format | |
| Page Count | 3,932 pages |
| File Size | 171.61 MB |
Models and Configurations Covered
The 47961275 publication is broader than a standard CX210D manual. Its listed coverage includes CX210D LC and NLC versions, triple-articulation configurations, CX210D Long Reach LC, and CX230D NHD configurations for the Tier 4 Final EU market. ([turn0search8])
| Model | Configuration Coverage |
|---|---|
| CX210D | LC / NLC, including listed triple-articulation versions |
| CX210D Long Reach | LC Long Reach |
| CX230D | NHD / NHD triple-articulation versions |
CASE CX210D / CX230D Machine Information
| Specification | CX210D Reference Configuration |
|---|---|
| Engine | Isuzu AR-4HK1X |
| Engine Type | 4-cylinder turbocharged diesel |
| Displacement | 5.2 L |
| Emissions | Tier 4 Final |
| Net Power | 160 hp (119 kW) @ 1,800 rpm |
| Maximum Travel Speed | 3.5 mph (5.6 km/h) |
| Bucket Digging Force | 31,923 lbf (142 kN) standard; up to 34,621 lbf (154 kN) with Power Boost |
| Arm Digging Force | 25,179 lbf (112 kN) standard with the referenced arm |
| Drawbar Pull | 42,264 lbf (188 kN) |
| Operating Weight | Approximately 48,900 lb (22,200 kg), configuration dependent |
| Electrical System | 24 V |
| Standard Track Shoe | 800 mm (31.5 in.) |
The CX210D Long Reach is substantially different from the standard digging configuration. CASE lists the CX210D LR at approximately 23.5 tonnes, with a maximum digging depth of about 12.0 m and maximum reach of approximately 15.6 m, making the Long Reach version particularly suited to deep excavation, dredging, sloping and other extended-reach work. ([turn1search1])
What Is Included in the Manual?
The useful part of this publication is that it follows the excavator itself rather than providing generic construction-equipment information. The main repair sections cover:
- Engine — engine service and associated systems.
- Hydraulic Systems — hydraulic components, circuits and service procedures.
- Frames and Ballasting — structural and counterweight-related work.
- Tracks and Track Suspension — crawler and undercarriage service.
- Cab Climate Control — heating and air-conditioning components.
- Electrical Systems — electrical components, circuits and diagnosis.
- Booms, Dippers and Buckets — working-equipment repair information.
- Platform, Cab and Bodywork — operator-station and body components.
- Electrical Schematics — circuit diagrams for electrical troubleshooting.
- Hydraulic Schematics — hydraulic circuit references.
- Special Tool Index — applicable service-tool information.
Why the Long Reach Coverage Matters
The CX210D Long Reach is not simply a CX210D with a longer attachment. Its extended boom and arm change the machine's working envelope and make hydraulic, structural and attachment-related service particularly important. CASE developed the CX210D LR for applications such as deep trenching, sloping, demolition and dredging where conventional reach is insufficient. ([turn1search3])
Having a manual that specifically identifies the Long Reach configuration is therefore important when working on the boom, dipper, bucket linkage, hydraulic circuits or related structural components.
Useful PDF Reference for Repair Work
The identified digital edition contains 3,932 pages and approximately 171.61 MB of PDF content. It is organized into major machine systems and includes hydraulic and electrical schematics, making it easier to locate the information needed for a particular repair rather than working through an unrelated generic excavator manual. ([turn0search7])
- English-language PDF
- Searchable digital manual
- Printable repair information
- Zoomable diagrams and schematics
- Detailed component service information
- Hydraulic and electrical schematics included
- Suitable for workshop or field reference
Frequently Asked Questions
What machines does CASE 47961275 cover?
It covers the CASE CX210D, CX210D Long Reach and CX230D Tier 4 Final configurations identified for the European market.
What is the publication number?
The service manual publication number is 47961275.
How many pages are in the CASE CX210D CX230D service manual?
The identified PDF edition contains 3,932 pages and is listed at approximately 171.61 MB.
Does this manual cover the CX210D Long Reach?
Yes. The publication specifically lists the CX210D Long Reach LC Tier 4 Final configuration.
Does it include hydraulic and electrical schematics?
Yes. Hydraulic and electrical schematics are included along with the corresponding machine-system service sections.
Is this an operator's manual?
No. This is a Service Manual intended for maintenance, troubleshooting and repair work. CASE also has a separate operator's manual for these machines.
