Case CX17C Mini Excavator PDF Repair and Service Manual

When a compact excavator starts losing hydraulic performance, tracking unevenly, overheating, or developing an electrical fault, the visible symptom is not always where the actual problem begins. The Case CX17C Mini Excavator Repair and Service Manual is built around the machine's individual systems, giving technicians a much more useful reference for tracing faults through the engine, hydraulic circuits, travel system, boom, arm, bucket, dozer blade, electrical system and upper structure.

This service documentation is for the CASE CX17C Canopy with Tier 4A engine. The identified April 2017 edition carries Part Number 48127447, is in English, and is listed as a 1,072-page PDF. The manual also includes dedicated electrical and hydraulic schematics identified as 48125608EN and 48125602EN.

CASE CX17C Machine Information

Machine Specification	CX17C Information
Manufacturer	CASE Construction Equipment
Model	CX17C
Machine Type	Mini Excavator
Engine	Kubota D902 diesel
Engine Configuration	3-cylinder, water-cooled diesel
Displacement	898 cc (54.8 cu in)
Gross Engine Power	16.8 hp (12.5 kW) at 2,300 rpm
Net Engine Power	15.8 hp (11.8 kW) at 2,300 rpm
Maximum Engine Torque	39.5 lb-ft (53.5 Nm) at 1,900 rpm
Operating Weight – Canopy, Short Arm	3,910 lb (1,775 kg)
Operating Weight – Long Arm with Counterweight	4,110 lb (1,865 kg)
Main Hydraulic Pumps	Variable-displacement tandem axial-piston pump plus gear pump
Maximum Rated Hydraulic Flow	2 × 5 + 3 gpm (2 × 18.8 + 11.3 L/min)
Auxiliary Hydraulic Flow	7.9 gpm (30 L/min)
Standard Hydraulic Relief Pressure	2,990 psi (206 bar)
Overload Relief Valve Pressure	3,270 psi (225 bar)
Fuel Capacity	5.3 gal (20 L)
Hydraulic Tank Refill Capacity	3.4 gal (13 L)
Total Hydraulic System Capacity	6.1 gal (23 L)
Travel Speed – Low	1.4 mph (2.2 km/h)
Travel Speed – High	2.6 mph (4.2 km/h)
Maximum Traction Force	3,300 lb (1,420 kg)
Maximum Gradeability	30° (58%)
Swing Speed	0–9.5 rpm
Track Configuration	Rubber tracks with extendable undercarriage

The machine specifications above are based on CASE technical literature for the CX17C. CASE identifies the machine with the Kubota D902 engine, tandem axial-piston/gear-pump hydraulic arrangement, fully hydrostatic track drive and 2-speed travel system.

Manual Identification & PDF Details

Manual Detail	Information
Manual Type	Service / Repair Manual
Machine	CASE CX17C Mini Excavator
Configuration	CX17C Canopy – Tier 4A Engine
Part Number	48127447
Edition	April 2017
Language	English
Format	PDF
Page Count	1,072 pages
Electrical Schematic	48125608EN
Hydraulic Schematic	48125602EN
Primary Use	Workshop repair, troubleshooting, inspection, maintenance and component service

The 1,072-page figure and 39.3–39.4 MB file-size listings apply to the identified digital reproduction of Part No. 48127447. Because different PDF reproductions can be compressed differently, file size can vary even when the page count and publication number are the same.

Hydraulic System: The Core of CX17C Service Work

The CX17C's compact dimensions do not mean its hydraulic system is simple. CASE specifies a variable-displacement tandem axial-piston pump combined with a gear pump, with a maximum rated flow of 2 × 5 + 3 gpm. The machine also provides an auxiliary hydraulic circuit capable of approximately 7.9 gpm at the published pressure specification.

That makes the hydraulic sections of the service manual particularly valuable when a CX17C develops slow boom movement, weak arm digging force, poor bucket response, reduced auxiliary attachment performance, hydraulic overheating, pressure loss or inconsistent operation.

• Hydraulic pump inspection and service
• Main control-valve information
• Hydraulic circuit troubleshooting
• Hydraulic cylinders and associated components
• Auxiliary hydraulic circuit service
• Hydraulic system specifications
• Hydraulic schematic interpretation
• Component removal and installation procedures

Engine and Fuel-System Repair

The CX17C uses the Kubota D902, an 898 cc three-cylinder water-cooled diesel engine. CASE lists gross power at 16.8 hp and net power at 15.8 hp at 2,300 rpm, with maximum torque of 39.5 lb-ft at 1,900 rpm.

For a small excavator, maintaining consistent engine output is important because the engine simultaneously supports hydraulic work and machine travel. A complaint such as engine bogging under hydraulic load, difficult starting, overheating, abnormal smoke or loss of power should therefore be investigated through the engine and associated systems rather than treating it as a purely hydraulic fault.

The service manual's engine section is organized into detailed engine and crankcase subjects, including areas such as the valve drive, cylinder head, connecting rods, pistons, crankshaft and flywheel.

Track Drive and Undercarriage Troubleshooting

The CX17C uses a fully hydrostatic drive system, automatic two-speed travel and rubber tracks. CASE also specifies an extendable track undercarriage.

When one side travels differently from the other, the machine struggles on an incline, travel speed drops, or a track-related component requires service, the repair process can involve more than the track itself. The manual includes dedicated information for tracks and track suspension, allowing the technician to examine the undercarriage alongside the hydraulic and travel systems.

Boom, Arm, Bucket and Swing Service

Excavation performance depends on several hydraulic actuators working together. A digging complaint can therefore originate in the boom, dipper/arm, bucket, swing or the hydraulic supply feeding those functions.

The CX17C manual separates booms, dippers and buckets into their own service area. It also includes information for the hydraulic system and swing-related components, providing a useful reference when dealing with slow cylinder movement, leakage, unusual play, poor digging response or a boom/arm function that does not behave normally.

Dozer Blade and Arm Information

The front dozer assembly is not simply an attachment to be ignored during service. The CX17C documentation includes a dedicated Dozer Blade and Arm section, making the manual relevant when the blade cylinder, linkage or associated structure requires inspection or repair.

This can be particularly useful on machines used for grading, backfilling and site preparation, where the dozer blade sees repeated loading in addition to the excavator's digging cycle.

Electrical Diagnosis and Schematics

Electrical problems on compact excavators can create symptoms that appear mechanical at first. A starting issue may be caused by an electrical circuit; a warning or control problem may originate from wiring or a component; and a machine function that suddenly stops responding may require electrical testing before hydraulic parts are replaced.

TM 48127447 includes an Electrical Systems section as well as the dedicated CX17C Electrical Schematic 48125608EN. This combination gives technicians both component/system information and a dedicated schematic reference for tracing circuits.

Frame, Platform and Operator Area

The repair coverage extends beyond the powertrain and working equipment. The manual includes Frames and Ballasting together with Platform, Cab, Bodywork and Decals. These sections are useful when service work reaches the upper structure, canopy area, body panels, mounting components or frame-related assemblies.

For an older or heavily used CX17C, this broader coverage can be important because wear and damage are not always limited to the hydraulic components responsible for the machine's primary work functions.

Technical Contents of the Manual

Manual Section	Coverage
Introduction	Safety rules, workshop practices, specifications, weights and dimensions
Engine	Engine and crankcase, valve drive, cylinder head, pistons, crankshaft and related engine service
Hydraulic Systems	Main hydraulic components, control valve, cylinders, circuits, troubleshooting and service
Frames and Ballasting	Frame and counterweight-related service information
Tracks and Track Suspension	Track system and undercarriage-related service
Electrical Systems	Electrical components, system diagnosis and related service information
Booms, Dippers and Buckets	Excavator working equipment and associated components
Dozer Blade and Arm	Blade, arm and related service information
Platform, Cab, Bodywork and Decals	Operator area, platform, bodywork and related components
Electrical Schematic	CX17C electrical schematic 48125608EN
Hydraulic Schematic	CX17C hydraulic schematic 48125602EN
Special Tools Index	Reference for applicable service tools

The section structure is documented in the service manual contents and is also reflected in current manual listings.

Useful Repair Scenarios for the CX17C

Rather than using the same generic troubleshooting language found on many equipment pages, the following situations are tied directly to the systems used on the CX17C:

• Excavator digs weakly: compare hydraulic-system behaviour with pump, control-valve, cylinder and pressure information before replacing the actuator.
• One track is slower than the other: investigate the hydrostatic travel circuit and track-related components instead of assuming the track itself is worn out.
• Auxiliary attachment loses power: examine the auxiliary hydraulic circuit, flow and pressure information.
• Engine loses rpm during digging: investigate engine performance together with the hydraulic load being imposed on the power unit.
• Machine overheats: inspect the engine cooling system and hydraulic operating conditions rather than treating temperature as an isolated symptom.
• Boom or arm cylinder leaks: use the hydraulic and working-equipment sections for component service and replacement procedures.
• Electrical starting fault: use the electrical-system information and schematic to trace the relevant circuit.
• Dozer blade requires rebuilding: use the dedicated blade and arm section for the applicable component service.

PDF Features for Workshop Use

• Format: PDF
• Language: English
• Page Count: 1,072 pages for the identified 48127447 edition
• Publication: CASE 48127447
• Digital File Size: approximately 39.3–39.4 MB in the identified listings
• Searchable digital reference for locating individual repair subjects.
• Zoomable technical illustrations and diagrams.
• Printable pages for workshop reference.
• Dedicated hydraulic and electrical schematics.
• Detailed component-level repair and service information.

Frequently Asked Questions

What machine does this Case service manual cover?

This manual is for the CASE CX17C Mini Excavator, specifically the canopy configuration with the Tier 4A engine.

What is the CASE CX17C service manual part number?

The identified April 2017 service manual is 48127447.

How many pages are in the CX17C repair manual?

The identified PDF edition contains 1,072 pages.

What engine does the CX17C use?

The CX17C uses the Kubota D902 three-cylinder diesel engine with 898 cc displacement. CASE lists 16.8 hp gross power at 2,300 rpm.

What hydraulic pump system does the CX17C have?

The machine uses a variable-displacement tandem axial-piston pump together with a gear pump. Maximum rated flow is listed as 2 × 5 + 3 gpm.

Does the manual include the hydraulic schematic?

Yes. The documentation identifies the CX17C Hydraulic Schematic 48125602EN.

Does it include an electrical wiring schematic?

Yes. An Electrical Schematic for the CX17C Excavator, 48125608EN, is included in the documented service material.

Does the manual cover tracks and the undercarriage?

Yes. Tracks and Track Suspension are a dedicated section of the service manual.

Does it cover the boom, arm and bucket?

Yes. Booms, Dippers and Buckets are covered in a separate service section, alongside the hydraulic-system information required for their operation.

Can this manual be used for engine repairs?

Yes. The engine section includes detailed engine and crankcase subjects as well as major internal engine components and service procedures.

What is the CX17C operating weight?

The published canopy operating weight is approximately 1,775 kg (3,910 lb) with the short arm and approximately 1,865 kg (4,110 lb) with the long arm and additional counterweight.

Case CX17C Mini Excavator Service Manual PDF

The Case CX17C sits in the compact end of the excavator range, but its service requirements extend across a surprisingly broad collection of systems: a Kubota three-cylinder diesel, tandem hydraulic pumps, hydrostatic track drive, swing system, boom and arm hydraulics, auxiliary hydraulics, electrical circuits and a compact undercarriage.

That is why CASE 48127447 is more useful as a workshop reference than a generic mini-excavator guide. It brings together the machine's engine, hydraulic systems, tracks, electrical systems, excavator working equipment, dozer blade, frame, operator platform and dedicated hydraulic/electrical schematics in one technical publication.

For technicians, mechanics, equipment owners and service professionals working on the applicable CX17C configuration, this Case CX17C Mini Excavator PDF Repair and Service Manual provides detailed information for troubleshooting, maintenance, component removal and installation, inspection, adjustment and repair.
